Overview

Sine labore streamline logistics operationes tuas cum nostris ASTM A513 Grade 1010 Precision Gravity Conveyor Roller Tubing. Praesto in magnitudinibus ab 1.181 ad 4.500 pollices (Ø30-114.3 mm) diametri exterioris (OD) et 0.039 ad 0.120 digitorum (1–3 mm) crassitudinis parietis (WT), incluso industria-vexillo 2 in x 0.065 in (Ø50.8 x 1.65 mm) et magnitudines leves sicut 1.75 in x 0.059 in (Ø44.5 x 1.5 mm), hae er-44.5 x 1.5 mm rotunditatis TRADUCTOR scutulis in logisticis, horreis et packaging. Machinati ad leve pondus ad materiam pertractandam medium-officium, fluxum sine labore materiali curant cum usibus secundis minimis in componentibus structuralibus. Compatibilia cum signis sicut EN 10305-3 et DIN 2394, complementa Tubingae nostrae systemata TRADUCTOR amplis gravitatis.

Cur elige Gravity Conveyor Roller Tubing?

· Sumptus efficax fortitudo: Gradus 1010 praebent cede robur ~310 N/mm², specimen gravitatis leve TRADUCTOR scutulis.
· Stricta tolerantiae: Dimensiones praecisae (v.g., 2 in/Ø50.8 mm OD ±0.005 in, 0.065 in/1,65 mm WT ± 10%), inconsutilem cylindrum conventum ac rotationem laevem obtinent.
· Humilis friction Superficies: Mundus, superficies uniformes frictionem extenuant, amplificandae gravitatis cylindro perficiendi et longitudinis.
· Levis Design: Ferri carbonis demissa subsidia inferiora ad media onera in systematibus TRADUCTORIA non-potentibus sustinet.
·Global-Latin Amplitudo: Magnitudines sicut 2 in x 0.065 in (Ø50.8 x 1.65 mm), 1.75 in x 0.059 in (Ø44.5 x 1.5 mm), et 2.25 in x 0.079 in (Ø57.2 x 2 mm) occurrit gravitas universalis TRADUCTORII necessariorum.
· Solutio oeconomica: Gradus 1010 certas operationes tradit in competitive sumptuum pro gravitatis scutulis.

Commune Steel Gradus ad Gravitas Conveyor Rollers

Noster ASTM A513 Gradus 1010 Tubinga aliis gradibus gravitatis et applicationis TRADUCTORII completur:

·ASTM A513 1010: Ferri carbonis inferioris (vim cede: ~310 N/mm², vires distrahentes: ~379 N/mm²) pro levitate gravitatis cylindrorum in mercibus (v.g., 2 in x 0.065 in / Ø50.8 x 1.65 mm).
·ASTM A513 1008; Ferri carbonis ultra-humilis (vim cede: ~275 N/mm², vires distrahentes: ~340 N/mm²) pro gravitatis umbilici cost-effective, leve ponderis (exampla, 1.5 in x 0.059 in / Ø38.0 x 1.5 mm).
·ASTM A513 1015; Vires libratae (vim cedunt: ~345 N/mm², vires distrahentes: ~414 N/mm²) pro medio-officio gravitatis cylindrorum in logisticis (v.g., 1.9 in x 0.059 in / Ø48.3 x 1.5 mm).
·ASTM A513 1018; Fortitudo moderata (vires cede: ~370 N/mm², vires distrahentes: ~440 N/mm²) pro gravitatis medio-officio scutulis (v.g., 1.75 in x 0.059 in / 44.5 x 1.5 mm).
·ASTM A513 1020; Vires superiores (vires cedunt: ~379 N/mm², vires distrahentes: ~ 448 N/mm²) ad medium-officium scutulis (v.g., 2.25 in x 0.079 in / 57.2 x 2 mm).
·ASTM A513 1026; Altae vires (vires cedunt: ~448 N/mm², vires distrahentes: ~517 N/mm²) ad graviores applicationes TRADUCTOR (v.g., 4 in x 0,120 in / 101.6 x 3 mm, vide nostrum grave officium Tubing-range).
·E220 (EN 10305-3); Ferri carbonis ultra-humilis (vim cede: 220 N/mm², vires distrahentes: 330-470 N/mm²) pro levitate gravitatis cylindrorum (exempli gratia, 1.969 in x 0.059 in / Ø50 x 1.5 mm).
·E235 (EN 10305-3); Ferri carbonis inferioris (vim cede: 235 N/mm², vires distrahentes: 340-480 N/mm²), aequivalens DIN 2394 ST37.2, pro umbilici medio-officii (exempli gratia, 2.374 in x 0.079 in / 60.3 x 2 mm).
·E275 (EN 10305-3); Fortitudo moderata (vires cede: 275 N/mm², vires distrahentes: 410-550 N/mm²) pro gravitatis medio-officio scutulis (v.g., 3 in x 0.083 in / Ø76.2 x 2.1 mm).
·ASTM A500 Gradus B: Ferrum structurale-gradus (vim cede: ~317 N/mm², vires distrahentes: ~400 N/mm²) gravioribus scutulis (v.g., 4.5 in x 0,20 in / 114.3 x 3 mm;
·AISI 304 (EN 1.4301); Ferrum immaculatum pro gravitatis corrosioni-resistenti cylindris in ambitibus hygienicis (v.g., 2 in x 0.059 in / Ø50.8 x 1.5 mm).

Hi gradus versatilem pro vectoribus gravitatis obtinent, cum gravioribus gradibus ad systemata potentatum prompti (v.g., DIN 2394 ST37.2, EN 10305-3 E355).

Vestibulum Process

Nostra ASTM A513 Grade 1010 gravitas TRADUCTOR cylindrus Tubing fabricatur ad praecisionem et firmitatem;

Electric resistentia 1. Welding (ERW); Ferri fasciae conflati et frigido-formatae ad certas dimensiones efficiendas (exempli gratia, 2 in x 0.065 in / Ø50.8 x 1.65 mm), efficiunt qualitatem ERW ferro Tubing.
2. Frigus formans: Adaequat subtilitatem dimensionalem et qualitatem superficiei ad rotationem lenis in gravitatis scutulis.
3. Caloris Curatio: Conditiones mechanicae optimize sicut-iunctae vel normalizatae proprietates leves materiales tractantes.
4. Superficies Consummatione: Levis, superficies mundae, saepe unctae vel phosphatae, resistentiam corrosionis obtinent et effectus frictionis humilis.
5. Qualitas Testis: Cohibet dimensiva, tentatio distrahens, et probatio non perniciosa (e.g., torsit current) obsequium cum signis ASTM A513 invigilat.

Hic processus praecisionem iuncta Tubing tradit optimized gravitatis TRADUCTOR cylindrus effectus.

Materia Specifications

Gradus: ASTM A513 Grade 1010, cum bene pro 1008, 1015, 1018, 1020, 1026, EN 10305-3 E220, E235, E275, AISI 304
Compositio chemica (Grade MX, Max% nisi certa):
·Carbon (C): 0.08–0.13
· Manganese (Mn): 0.30-0.60
·Phosphorus (P): 0.035
· Sulfur(S): 0.035
Mechanica Properties (Grade MX, As-Welded);
· Virtus cede: ~310 N/mm²
· fortitudo distrahens: ~379 N/mm²
·Prolongatio: 15% (min)

Magnitudo dolor:

Diameter exterior (OD); 1.181-4.500 in (Ø30-114.3 mm)
Murus Crassitudo (WT); 0.039-0.120 in (1-3 mm)
Longitudo; Random (3.3–40 ft / 1,000-12,000 mm) vel consuetudo cut
Communia Amplitudo pro Gravity Conveyor Rollers (OD x WT);
·1.5 in x 0.059 in (Ø38.0 x 1,5 mm, gravitatis ponderibus levibus)
·1.75 in x 0.059 in (Ø44.5 x 1.5 mm, gravitatis leves scutulis)
·1.9 in x 0.059 in (Ø48.3 x 1.5 mm longis, gravitatis mensurae vexillum)
·2.0 in x 0.065 in (Ø50.8 x 1.65 mm, regula gravitatis scutulis)
·2.25 in x 0.079 in (Ø57.2 x 2 mm, gravitatis medio-officium scutulis)
·2.374 in x 0.079 in (Ø60.3 x 2 mm, gravitatis medio-officium scutulis)
·2.5 in x 0.079 in (Ø63.5 x 2 mm, gravitatis medio-officium scutulis)
·3.0 in x 0.083 in (Ø76.2 x 2.1 mm, gravitatis medio-officium scutulis)
·3.5 in x 0.098 in (Ø88.9 x 2.5 mm, gravitatis umbilici gravioris)
·4.0 in x 0.120 in (Ø101.6 x 3 mm, summus capacitas scutulis; vide grave officium range)
·4.5 in x 0.120 in (Ø114.3 x 3 mm, summus capacitas scutulis; vide grave officium range)

Tolerantia (per ASTM A513);

·OD (≤2.5 in): ±0.005 in; (>2.5-4.5 in): ±0.006 in
·WT: ±10%
·Longitudo: ±0.12 in (±3 mm) pro longitudinibus sectis
· Conditiones: sicut-iuncta, Normalised
· Conditiones Superficies: lenis, mundus, vel iactaret (uncti / phosphated) pro corrosione resistentiae

Applications

Noster ASTM A513 Gradus 1010 et aliae praecisiones fistulae (exempli gratia, 2 in x 0.065 in / Ø50.8 x 1.65 mm, 1.75 in x 0.059 in / Ø44.5 x 1.5 mm) designantur:

Gravitas Conveyor Rollers: Princeps perficientur Tubing pro non-powered materia tractandi systemata in:
1. Logistics: Apothecae, distributio centra pro parvis fasciculis mediantibus (1010, 1008, 2 in x 0.065 in; E220, Ø44.5 x 1.5 mm).
2. Packaging: E-commerce, particula tractandi (1015, 1018, 1.9 in x 0.059 in; E235, Ø57.2 x 2 mm).
3. Vestibulum: Conventus lineae, levis industriae gravitas transvehentium (1010, 2.25 in x 0.079 in; E275, Ø63.5 x 2 mm).
4. Hygienic Environments: Processus cibi, veneficiis (AISI 304, 2 in x 0.059 in).
5. Secundarium Applications (limited usus);
· Partes structurae leves (e.g., tabulae cum ASTM A500 Grade B).
· Lorem tubing (exampla, devexum 1008, E220).

Gravius officium aut vectores potentes explorare nostrum DIN 2394 ST37.2 vel EN 10305-3 E355 Tubing.

Quality Assurance

Omnes Gradus 1010, 1008, 1015, 1018, et aliae fistulae cum ASTM A513, EN 10305-3 obtemperant, vel signa pertinentia. Test testimoniales per DIN EN 10204 3.1 comprobant compositionem chemicam, proprietates mechanicas et accurationem dimensionalem. Vena probatio, adulatione probat, et inspectiones superficiei invigilant ad summum faciendum gravitatis TRADUCTOR Tubing.

Optimize Gravity Conveyor Efficens

· Designed for Effless flow: Magnitudines sicut 2 in x 0.065 in (Ø50.8 x 1.65 mm), 1.75 in x 0.059 in (Ø44.5 x 1.5 mm), et 2.25 in x 0.079 in (Ø57.2 x 2 mm), cum gradibus 1010 ad AISI 304, rotationem lenis et durabilitatem obtinent.
· Signa Obsequium Global: ASTM A513, EN 10305-3, et DIN 2394 optiones compatibiles quae in mercatu totius mundi indigent.
· Flexibile Supple: Instructus vexillum magnitudinum et longitudinum customizable propter necessitates gravitatis TRADUCTOR.
· Guidance Peritus: Bigas nostra adiuvat es eligere specimen gradus et magnitudo ad maximam efficientiam.
