Custom Fabricated Tubing - Steel / Steel, Bent & Welded, customized Dimensiones and Figuras

Custom nostra Tubing fabricata praecisionem inflexam, iunctam, tubulatam formandam praebet pro tuis structuris, industrialibus et mechanicis applicationibus..

Nunc Interroga

Hoc includit:

·Carbon chalybeum (ASTM A513 1020, ASTM A519 4140, EN 10305-2 E235)
· Sine ferro (AISI 304, AISI 316);
· Consuetudo dimensionum: OD, ID, muri crassitudo et longitudo
· Formae consuetudinis: Rotundae, quadratae, rectangulae, et perfiles implicatae
·Wolding and finishing: MIG/TIG, politus, obductis, vel galvanized
· Specimen systematum hydraulicarum, machinae industriae, structurae autocineticae, compages constructionis, et aliae applicationes ubi vexillum Tubing non potest occurrere requisitis design.

Typical Materials & Grades

Steel Gradus	Features	Exemplum Amplitudo / Applications
ASTM A513 1020	N/mm², tensile ~420 N/mm²	50.8 × 2 mm, rotundum, autocinetum & structural
ASTM A519 4140	N/mm², distrahens ~862 N/mm²	76.2 3 mm, grave officium machinarum
EN 10305-2 E235	Subtilitas chalybis carbonis, applicationes leves	50 50 2 mm, quadratum
AISI 304 (EN 1.4301)	Diver immaculatus, corrosio repugnans	50.8 × 2 mm, rotundum, constructione & industriae
AISI 316 (EN 1.4401)	Consectetur marinis corrosio resistentia / chemical	60 40 2 mm, rectangulum

Hi gradus applicationes in autocinetis, constructionibus, industrialibus et marinis ambitibus adiuvant, post ASTM et EN signa.

Why Choose Our Custom Fabricated Tubing?

· Design flexibile: Inflexis et iuncta subtilibus rotundis, quadratis vel rectangulis formis
· Fortitudo : Carbon et mixturae ferri bene pro gravibus applicationibus officiorum
· Corrosio Resistentia: Diver bene pro dura ambitibus
· Subtilitas tolerantiae: e.g., Ø50.8 mm OD ± 0,1 mm, 2 mm WT ± 10%
· Magnitudines & Figurae Versatiles: Rotundae, quadratae, perfiles rectangulae
· Sumptus-effective Customization: Qualis fabricationis ad competitive sumptibus

Communia Amplitudo et Figurae

Profile	Typical Amplitudo	Notae
Circum	Ø12.7–101.6 mm	e.g., Ø50.8 × 2 mm pro tabulis autocinetis
Quadratus	20 20 mm ad 100 100 mm	e.g., 50 × 50 2 mm ad subsidia structurarum
Rectangulare	40 60 mm usque ad 100 60 mm	e.g., 60 40 2 mm pro machinarum tabulis
Murus Crassitudo	1-5 mm	Dependens OD / ID et onus iudicium
Longitudo	Ad XII m *	Custom-Conscidisti per Lorem speciem

Vestibulum Process

1. Tube Electio: Frigidus tractus vel calidus-volutus, ex ferro gradus
2. -hoc; In rotundum, quadratum, rectangulum, vel in consuetudine profiles
3. tendentes; CNC praecisio inflexionis ad angulos exactos et radios
4. Welding: MIG, TIG, vel ERW glutino pro articulis validis, inconsutilibus
5. Superficies Consummatione: Expolitum (Ra ≤0.8 µm pro immaculata, Ra ≤1.6 µm pro chalybe carbo) vel obductis (perunctis, galvanizatis)
6. Qualitas Testis: Cohibita dimensiva, solida integritas, ac probatio non perniciosa

Materia Specificationes

ASTM A513 1020 (Max%)

·C: 0.18–0.23 | Mn: 0.30–0.60 | P: 0.04 | S: 0.05
·Mechanical: N/mm², tensile ~420 N/mm², Prolongatio 15%
AISI 304 (Max%)

·C: 0.08 | Mn: 2.0 | P: 0.045 | S: 0.03 | Cr: 18-20 | Ni: 8-10.5
·Mechanical: N/mm², tensile 515–690 N/mm², Prolongatio 40%

Tolerantiae (per ASTM A513)

·OD (Circiter); ±0.1 mm (Ø12.7–76.2 mm), ±0.15 mm (>76.2–101.6 mm)
· Dimensiones ±0.15 mm
·WT: ±10%
·Longitudo: ±5 mm

Delivery Conditions

· Frigidum-tractum, Annealed, seu Normalised
· Conditiones superficies: polita, uncta vel galvanized

Applications

· Automotive: Inflexus systemata exhaurit, caveas volvunt, componentes gb
·Construction: Structura subsidia, cancelli, compages
·Industrial: Machinariae tabulae, systemata TRADUCTOR, caerimoniae consuetudo
·Marine / Chemical: Corrosio repugnans limbis et caerimonias
· Levis / Precision Components: Pars minimal secundarium usus

Pricing & Availability

· Aestimari: $2-$6 per kg (pendet in volumine, regione, flexione multiplicitate)
·Contactus pro consuetudine quotes at [inserta contactu singula]

Quality Assurance

·Prosequitur ASTM A513, A519, EN 10305-2 signa
DIN EN 10204 3.1 De compositione chemica, proprietatibus mechanicis et accuratione dimensiva
· Non perniciosius probatio, inspectio firma, probatio distrahens includitur
